Topsort coffee bean color sorting machine is an equipment used to sort coffee beans by color and shape. It uses optical sensors to detect the color and shape of each bean and then sorts them into different categories based on their hue and size. The machine can be used to sort green coffe beans, roasted coffee beans, blending, or packaging purposes.
Order(MOQ) :
1Payment :
TT/LCProduct Origin :
Hefei,ChinaColor :
White,can customizeLead Time :
Within 5-7 working daysCertificate :
CEProduct Name :
Coffee bean color sorting machineWarranty :
2 yearsModel :
TS4(R4-256)Machine Function :
color/shape/material sortingHow Does A Coffee Bean Color Sorter Works?
Feeding: Coffee beans are fed into the color sorter hopper, which allows the beans to flow evenly onto the chutes.
Inspection: As the beans move along the conveyor belt, they pass through a series of optical sensors or cameras. These sensors capture images of the beans in real-time.
Color recognition: The optical sensors analyze the color of each individual coffee bean by measuring the reflected light. The sensors detect variations in color based on predetermined criteria, which is typically set by the operator or programmed into the machine.
Comparison and sorting: The color information captured by the sensors is compared to the pre-set color criteria. If a bean falls within the acceptable color range, it is classified as a good bean and allowed to continue down the sorting line. If the bean's color is outside the acceptable range, it is classified as defective or undesired.
Ejection: Once a defective bean is identified, the color sorter activates a mechanism to remove it from the production line. This is typically done using air jets, mechanical paddles, or electromagnetic devices. The ejected beans are directed to a separate outlet or collection bin.
Sorting parameters: In addition to color, TOPSORT coffee bean color sorting machine can also sort beans based on other parameters like size, shape, and texture. These parameters further enhance the accuracy and precision of the sorting process.
Coffee Bean Color Sorting Machine Features
1. High-speed sorting: Coffee bean color sorter can sort thousands of kgs per hour, ensuring efficiency and accuracy in the sorting process
2. High sorting accuracy: The machine achieves 99.99% sorting accuracy and can distinguish between subtle differences in coffee bean color.
3. Color recognition technology: The machine uses advanced color recognition technology to identify individual coffee beans based on their color and shape.
4. Customizable sorting parameters: The machine allows operators to adjust sorting parameters based on specific requirements, such as bean size, shape, and color.
5. User-friendly interface: The machine has a user-friendly interface that allows operators to easily set up and run the sorting process.
6. Automatic reject system: The machine automatically rejects beans that do not meet the sorting criteria, ensuring only high-quality beans are selected.
7. High-capacity hopper: The machine has a large capacity hopper that can hold a significant quantity of coffee beans, reducing the need for frequent refilling.
8. Compact design: The machine has a compact design that takes up minimal space in a coffee processing facility.
4 Chutes Coffee Color Sorting Machine Technical Parameters
| Model | TS4(R4-256) |
| Channles | 256 |
| Power | 2.4kw |
| Weight | 650kgs |
| Dimensions | 1986*1504*1760mm |
| Power voltage | 220V/50HZ/60HZ |
| Sorting accuracy | 99.99% |
| Capacity | 1200-2400kgs/h |
| Air consumption | <4.0m3/min |
| Air pressure | 0.6-0.8Mpa |
Green coffee bean color sorting results
Roasted coffee bean color sorting results
Our Color Sorter Machine Core Advantages
Sucessful Cases
Why Choose TOPSORT Color Sorter
Top technology
Adopt high-speed FPGA digital image processing technology, faster detection speed, higher recognition rate and high sorting accuracy.we have CCD color sorter and infrared color sorter for different sorting requests.
Top quality
Equiped with imported famous brand key components to guarantee the reliability.Professional production team, each step is inspected by professional quality inspectors before moving on to the next process Before shipping the machine,our engineer will test and save parameters,make sure they are in good condition.
Competitive Price
Competitive price thanks to the mass production and lean production
Remote control for global
Machine equipped with WIFI device, online solve software parameters setting problems.
Free Training
We supply complete training for all customers for free,we train in the following ways:
1. Engineers go to customer site to explain how to adjust, use and maintain the machine.
2. Customers can also come to our factory to learn the knowledge related to the machine.
3. Online remote control training or video training is available if customer no need send engineer.
Fast Delivery
Safe stock of standard parts of the machine guarantees the quick delivery of the machine
